Overview

We would like you, to take a few minutes to review the following pages. We are excited to give you this information about us.

Our goal is to bring you, the customer, a highly motivated Tool and Die Shop, offering C.N.C. Machining in Mill, Lathe ,Wire EDM ,Ram EDM and Surface Grinding. We are dedicated to the sole pursuit of producing quality parts for the tooling and mold making industries.

The following highlights our company:
• C.N.C. Machining
• Advanced CAD/CAM capabilities
• Modern Facilities

We are anxious to build a solid working relationship and will strive to provide the best work for a reasonable cost.

Sincerely,
Rick Minman


Facilities


(1) Charmilles 290 AWF CNC Wire EDM
(10" x 15" x 8" x,y,z travel)
(1) Charmilles 310 AWF CNC Wire EDM
(10" x 15" x 15.75" x,y,z travel)
(1) Charmilles 230F AWF CNC Wire EDM
( 9" x 14" x 8" x,y,z travel)
(2) Hardinge Vertical Machining Center
(20" x 40" x 20" travel)
(1) Fanuc Vertical Machining Center
(20" x 16" x 12" travel)
(2) Okuma CNC Lathe / Live Tooling 10” Chuck
(1) Eltee 20 Ram EDM
(1) Charmilles RoboForm 31 CNC Ram EDM (16 Pos. T.C.)3-R and Irowa Macro Holders

Facilities


(3) Series 1 Bridgeport Manual Mill
(2) 6/14 Okamoto Surface Grinder
(3) 6/12 Harig Surface Grinder
(1) 12/24 Okamoto DX Grinder

(1) EDM Drillmate (Hole Popper)
(2) Roll-In Band Saw
(1) 12” Horizonal Saw
(1) 14" X 40" Engine Lathe

**** Cutting all conductive tool steels, aluminum, brass, copper, graphite, carbide, copper tungsten, and exotic aerospace materials

CAD / CAM Work Station


4 axis programming, cutting from your CAD data files or ours.

MasterCam, Solidworks and AutoCad.

Inspection Equipment


(1) Helmel CMM 16”x 20”x14”
(1) Covel Optical Comparator 14"
(4) Mitutoyo 12" Master Height Gage
(2) Mitutoyo Toolmakers Scope
(6) (81 Pcs.) Ceramic Gage Blocks
(1) O.G.P. Comparator 14" with Quad Check
(1) J&L Comparator 14” with Quad Check
(4) .011”-1.000” Gages Pins

Rick Minman

President/Owner

Rena Minman

Secretary

Leseen Acker

Bookkeeper





Where We Are

Precision Machining
Fixtures & Gages Prototypes
EDM Specialist
CNC Wire & RAM



Request Info

If you would like more information on Minco Tool, feel free to call or email us and a service representative will contact you shortly.

Minco Tool & Mold, Inc.

  • Phone:
    814-724-1376
  • Fax:
    814-724-1371
  • Address:
    370 Linden Ave
    Meadville, PA 16335
